12. APPENDIX 2
12-1. Preface
Feasible combinations of the SC202G conductivity transmitters with different styles of the PH201G dis-
tributor are listed in the table below. The distributor has the usual distributor functions (supply power to
transmitter, receive current output from transmitter, and provide analog output) as well as contact output
functions (maintenance, wash and fail status signals). Since the two transmitters provide different digital
signals to control the distributor contact outputs, two distributor styles are provided for compatibility. The
SC202G is not intrinsically safe (explosionproof), so never install it in a hazardous area.
T1.eps
Use of Distoributor PH201G
No use of contact output
Use of contact output
Conductivity
transmitter
Style A & Style B possible Only Style B possible
Refference
Non-Explosionproof type
SC202G
For information about instruments related to the SC202G, SC202S, refer to the following Instruction
Manuals.
Manual Name IM No. Instruments mentioned
Conductivity Sensor IM 12D08F03-02E SC4AJ
IM 12D08G02-01E SC8SG
IM 12D08G03-01E SC210G
PH201G distributor (Style B) IM 19B01E04-02E PH201G (Style B) Distributor
SDBT disributor IM 01B04T01-02E SDBT
SDBS disributor IM 01B04T02-02E SDBS
Attachment rack instrument IM 1B4F2-01E Instruments for rack attachment
