IM 12D08B02-01E
1-8 Appendix
ON LINE MENU
Level 1 menu Level
2
menu
Level 3 menu
Level 4menu Level 5menu
1. Process variables
2. Diag/Service
3. Basic setup
4. Detailed setup
5. Review
1. PV
2. Uncomp
3. Temp
4. PV % rnge
1. Status
2. Hold
3. Logbook
1. Logbook conf.
2. Logbook1
3. Logbook2
4. Loop test
1. Tag
2. Device information
1. Param. specific
2. Temp. specific
3. Temp. compensation
4. Output function
5. User interface
1. Hold status
2. Hold fnc.
3. Hold type
1. Date
2. Descriptor
3. Message
4. Write protect
5. Manufacturer
6. Dev id
1. PV unit
2. Electrodes
3. CC nom
4. CC act
5. Pol. check
1. Device setup
2. PV
3. AO1
4. LRV
5. URV
Note:
“2. PV” means
Primary value
“3. AO1” means
Analog output
“4. LRV” means
Lower rangeval
“5. URV” means
Upper rangeval
1. Ref. Temp
2. TC1 type
3. TC2 type
4. Matrix table
1. Auto. Ret
2. E5 lim.
3. E6 lim.
4. Percent
5. Fmt
6. USP
7. Passcodes
1. mA func.
2. Burn func.
3. mA-table
1. Maintenance
2. Commissioning
3. Service
1. Error prog.
2. Display
1. Temp. sens
2. Temp. unit
1. Powerup
2. Powerdwn
3. Defaults
4. Lg. Erased
5. Low range
6. High range
7. Hold on
8. Hold off
9. Error on
Error off
Temp. adj
Cell const
Air cal
Calibrate
Ref. temp
Temp. coef1
Matrix
Temp. coef2
1. Model
2. Manufacturer
3. Distributor
4. Tag
5. Descriptor
6. Message
7. Date
8. Dev id
9. Write protect
Universal rev
Fld dev rev
Software rev
Hardware rev
Poll addr
Num req preams
Err.1···Err.13
Note:
“Fmt” means displayed decimal point.
Note:
“Uncomp” means uncompensated value.
“PV % rnge” means % of output range.
(Note):
HART protocol DD files can be downloaded by following URL.
http://www.yokogawa.com/an/download/an-dl-fieldbus-001en.htm
Menu structure for HHT 375 shown below.
