5. BASIC OPERATING PROCEDURES
(DISPLAY)
Data is changed with the three keys on the indicator
(SET, SHIFT and INC) or by using the HART
Conguration Tool.
5.1 Conguration of Display
SET
INCSHIFT
N
S
kor
t
d
M
J 00
K
Mk
k
%
FS
MC
d/ /s
ni
m
/
h/
U
b
g
t
S
t
d
N
o
r
x
10
ra
b
i
sp
A
°
F
C
°
x
1
0
b
g
t
x1
0
al
c
f
aP
a
l
c
f
m
3
TE .PMAU .XTO LAT PR .SSE
U
m
3
-
3
6
36
-
b
l
bl
B
TM
J
BT
6
3
4
1
2
5
Figure 5.1 Conguration of Display
1 Indicator upper display:
This displays the owrate data, temperature
data and other setting item No.
2 Indicator lower display:
This displays temperature/pressure/density
data, alarm No. and data settings based on total
data, temperature data and analog input.
3 Alarm icon:
This displays if a serious alarm has occurred.
Serious alarms are system alarms and process
alarms.
4 Write protect icon:
This displays the write protect status.
5 NE107 category icon
This displays the NE107 category.
6 Setting switch:
This switch is used to change the owrate data
indication and the content of setting data
For details on how to set from other indicators,
refer to the Communications Manual listed in
Table 1.1 Related Documents.
<5. Basic Operating Procedures (Display)>
32
IM 01F07A01-01EN
To Next Page
