■ Process Alarms
The device is normal but has malfunctioned and normal measurement is not possible due to process-related
problems. Maintenance, etc. is needed.
NE107
Error messages
Analog
output
Pulse
output
Frequency
output
Status
output
Vortex
frequency
Built-in
temperature
Analog
input
Instantaneous
ow rate
Fluid
temperature
Fluid
pressure
Fluid
density
Fluid
density
ratio
Specic
enthalpy
Flow rate
total
Indicator HART
S AL-030 030:Fluctuation Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-031 031:Transient noise Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-032 032:High vibration
User
setting
High
vibration
action
Operation Operation
User
setting
High
vibration
action
Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-033 033:Critical vibration
User
setting
Critical
vibration
action
Operation Operation
User
setting
Critical
vibration
action
Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-040
040:Temperature
out of range
Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-042
042:Analog output
out of range
Limit Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-043
043:Pulse output out
of range
Operation Limit Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-044
044:Analog input out
of range
Operation Operation Operation Operation Operation Limit
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
S AL-045
045:T/P
compensation out
of range
Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
■ Setting Alarms
The device is operating normally, however, a parameter setting error has occurred. Parameter must be set.
NE107
Error messages
Analog
output
Pulse
output
Frequency
output
Status
output
Vortex
frequency
Built-in
temperature
Analog
input
Instantaneous
ow rate
Fluid
temperature
Fluid
pressure
Fluid
density
Fluid
density
ratio
Specic
enthalpy
Flow rate
total
Indicator HART
C AL-050
050:Flow span
set error
Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
C AL-051
051:Temperature
span set error
Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
C AL-053
053:Flow
calculation set
error
Operation Operation Operation Operation Operation Operation Hold
Interlocked
to input
Interlocked
to input
Hold
Hold
C AL-054
054:Analog
output set error
Hold Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
C AL-055
055:Pulse output
set error
Operation Hold Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
C AL-056
056:Analog input
set error
Operation Operation Operation Operation Operation Hold
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
C AL-060
060:Sensor
backup error
Operation Operation Operation Operation Operation Operation
Interlocked
to input
Interlocked
to input
Interlocked
to input
Interlocked
to input
Operation
