YOKOGAWA WT210 User Manual

xiii
IM 760101-01E
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
Index
Chapter 11 Serial Interface (Option)
11.1 Serial Interface Functions and Specifications ................................................................ 11-1
11.2 Connecting the Interface Cable ..................................................................................... 11-3
11.3 Setting the Mode, Handshaking Method, Data Format and Baud Rate ......................... 11-5
11.4 Format and Commands of Output Data (before the IEEE488.2 Standard) ................... 11-8
Chapter 12 Initializing Setup Parameters, Zero-Level Compensation, and Key
Lock
12.1 Back-up of Setup Parameters ........................................................................................ 12-1
12.2 Initializing Setup Parameters ......................................................................................... 12-2
12.3 Performing Zero-Level Compensation ........................................................................... 12-4
12.4 Key Lock ........................................................................................................................ 12-5
Chapter 13 Communication Commands 1 (System of Commands before the
IEEE 488.2 Standard)
13.1 Commands..................................................................................................................... 13-1
13.2 Before Programming .................................................................................................... 13-16
13.3 Sample Program Image ............................................................................................... 13-18
13.4 Sample Program (Initialization, Error, and Execution Functions) ................................. 13-19
13.5 Sample Program (Output of Normal Measurement Data) ............................................ 13-22
13.6 Sample Program (Output of Harmonic Measurement Data) ........................................ 13-25
Chapter 14 Communication Commands 2 (System of Commands Complying to
the IEEE 488.2-1992 Standard)
14.1 Overview of IEEE 488.2-1992 ........................................................................................ 14-1
14.2 Program Format ............................................................................................................. 14-3
14.2.1 Symbols Used in Syntax Descriptions.............................................................. 14-3
14.2.2 Messages ......................................................................................................... 14-3
14.2.3 Commands ....................................................................................................... 14-5
14.2.4 Responses ....................................................................................................... 14-7
14.2.5 Data .................................................................................................................. 14-7
14.2.6 Synchronization with the Controller .................................................................. 14-9
14.3 Commands................................................................................................................... 14-11
14.3.1 Command List ................................................................................................ 14-11
14.3.2 AOUTput Group ............................................................................................. 14-15
14.3.3 COMMunicate Group ..................................................................................... 14-16
14.3.4 CONFigure Group .......................................................................................... 14-18
14.3.5 DISPlay Group ............................................................................................... 14-22
14.3.6 HARMonics Group ......................................................................................... 14-24
14.3.7 INTEGrate Group ........................................................................................... 14-25
14.3.8 MATH Group .................................................................................................. 14-26
14.3.9 MEASure Group ............................................................................................. 14-28
14.3.10 RECall Group ................................................................................................. 14-36
14.3.11 RELay Group.................................................................................................. 14-37
14.3.12 SAMPle Group ............................................................................................... 14-39
14.3.13 STATus Group ................................................................................................ 14-40
14.3.14 STORe Group ................................................................................................ 14-41
14.3.15 Common Command Group ............................................................................ 14-42
Content

YOKOGAWA WT210 Specifications

General

Brand	YOKOGAWA
Model	WT210
Category	Measuring Instruments
Language	English
