YOMANI ML/XR
OWNER MANUAL
34 unrestricted
last updated 3 May 16 document release 2.2 ymn_mlPower.fm
YOMANI ML with Merchant Unit
Only use the mains adaptor that is supplied by your vendor.
Always connect the Merchant Unit to the mains adaptor before plugging the mains
cable into the mains power socket.
1. Connect the YOMANI ML correctly to the Merchant Unit.
See Connecting the Merchant Unit - optional, on page [xref].
2. Connect the Merchant Unit to the mains adaptor.
3. Tie-wrap the cable to the power cable strain relief.
4. Connect the mains cable to the mains adaptor and plug it into the mains power
socket.
Both displays light up and the YOMANI ML is ready for use.
Figure 39. Power cable tie-wrapped to Merchant Unit
1 mains cable (to mains power socket)
2 power cable (from mains adaptor to Merchant Unit)
3 power input socket
4 strain-relief points on Merchant Unit
