YOMANI ML/XR
OWNER MANUAL
40 unrestricted
last updated 3 May 16 document release 2.2 ymn_using.fm
Using a printer
This description applies to using the printer in the Merchant Unit.
The description here is valid both for the printer in the Merchant Unit and for the
optional printer for the terminal.
Inserting paper
Only use paper approved by Worldline.
This paper can be recognized by the approval seal printed on the back of the paper. If
you want to order paper from your local paper supplier, contact your vendor.
1. Open the paper-roll cover, by pressing the release button as indicated below.
Figure 46. Opening the paper-roll cover – Merchant Unit
Figure 47. Opening the paper-roll cover – terminal
2. Unroll about 5 centimetres of paper, and insert it as shown on the sticker.
When inserting a new paper roll, make sure that:
– the paper reservoir is empty
– the paper is not cracked, wrinkled or sealed
– the paper comes out straight
