AFFZP0BB – ACE3 – User Manual Page – 139/139
To download parameters, proceed as follows:
1. Navigate the directory list and go into the directory where you want to save
the parameters.
2. If this directory already contains the subdirectory with the correct 8 digits go
to step 3. If it is not present, a new subdirectory will be created automatically.
Do not enter the subdirectory manually.
3. Press OK to start parameter download. A progression bar shows the ongoing
process.
4. When finished, press ESC so to return to MAIN MENU. USB stick can be
removed safely.
Connect the USB stick to a PC and enter the directory of point 1). A subdirectory
with the correct name and, inside this one, a csv file are present.
4 During download the led blinks slowly to indicate the console is running.
4 When download has finished USB stick can be unplugged safely.
U Do not remove USB stick during download or the file will result empty or
corrupted.
