Page – 88/139 AFFZP0BB – ACE3 – User Manual
Error code Effect Condition
Restart
procedure
CAN
OPEN
CODE
MDI
CODE
ZAPI
CODE
LED
CODE
VDC LINK OVERV.
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Stand-by, running
Valves or
Traction/Pump
Request
0XFFCA 77 202 77
Request
CONTACTOR CLOSED
MC is not closed
(command is not
activated),
EB is applied,
Traction/Pump stopped
Start-up
Valves or
Traction/Pump
Request
0x5442 37 37
37
CONTACTOR OPEN
MC is opened,
EB is applied,
Traction/Pump, valves
stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
Request
0x5441 38 38
38
POWER MISMATCH
Traction is stopped
EB is applied,
MC is opened
Running
Traction/ Pump
request
0xFFD4 39 212
39
WRONG SET BAT
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up
The alarms
disappears as soon
as the voltage
comes back into the
correct range
0x3100 41 251 41
MOT.PHASE SH.36
MOT.PHASE SH.37
MOT.PHASE SH.38
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up
Traction/ Pump
request
0xFFC4 47 196 47
STBY I HIGH
MC is not closed,
EB is applied,
Traction/Pump stopped
Start-up, stand-by
Valves or
Traction/Pump
Request
0x2311 53 53 53
OVERLOAD Traction is stopped Running Key re-cycle 0xFFB4 57 180 57
CAPACITOR CHARGE
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up
Valves or
Traction/Pump
Request
0x3130 60 60 60
TILLER ERROR
Traction stopped, EB
applied
Stand-by, running
Valves or
Traction/Pump
Request
0xFFB9 64 185
64
NO CAN MSG.
MC is opened, EB is
applied, Traction/Pump,
valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
Request
0X8130 67 248 67
WRONG RAM MEM.
MC is opened, EB is
applied, Traction/Pump,
valves stopped
Stand-by Key re-cycle
0xFFD2 71 210
71
DRIVER SHORTED
MC is opened (the
command is released), EB
is applied, Traction/Pump,
valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
Request
0x3211 74 74 74
CONTACTOR DRIVER
MC is opened (the
command is released), EB
is applied, Traction/Pump,
valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
Request
0x3221 75 75 75
MC-EF COIL SHOR.
MC is opened,
EB is applied,
Traction/Pump, valves
stopped
Start-up
(immediately after
MC closing), stand-
by, running
Valves or
Traction/Pump
Request
0x2250 76 223 76
SPEED FB. ERROR
MC is opened , EB is
applied,
EVP stopped
Running Key re-cycle 0xFFAF 81 175 81
ENCODER ERROR
MC is opened, EB is
applied, Traction/Pump,
Running
Valves or
Traction/Pump
0xFF52 82 82
82
