ZCS AZZURRO 1PH HYD3000-ZP1 User Manual

User’s Manual 1PH HYD3000-HYD6000-ZP1
Rev. 1.
0 01/09/2023
Identification: MD-AL-GI-00
Rev. 1.1 of
27/01/2023 - Application: GID
104/193
10.4. Main menu
In the main interface, press the “Down” button to enter the page with the grid/battery/PV settings:
Main interface
Press “Down”
Grid Output Information
Grid(V)
Grid(A)
Frequency
Battery information
Battery(V)
Battery current(A)
Battery power(kW)
Battery temperature(°C)
Battery SOC(%)
Battery cycles(T)
PV Information
PV1 Voltage(V)
PV1 Current(A)
PV1 Power(kW)
PV2 Voltage(V)
PV2 Current(A)
PV2 Power(kW)
Inverter Temperature(°C)
In the main interface, press “Back” to enter the main menu. The main menu has the following five options:
Main interface
Press “Back”
“Up” ↑
“Down” ↓
1.System Settings
2.Advanced Settings
3.Energy Statistic
4.System Information
5.Event List
6.Software Update
7.Battery Real-time
Information

ZCS AZZURRO 1PH HYD3000-ZP1 Specifications

General

Max. DC Voltage	550 V
Nominal AC Voltage	230 V
DC Connection	MC4
Protection Degree	IP65
Cooling	Natural convection
AC Voltage Range	180-276 V
Max. Efficiency	97.6 %
Operating Temperature Range	-25°C to +60°C
Frequency	50/60 Hz
Efficiency	97.6 %
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit, Over Temperature
Storage Temperature	-40 °C / +70 °C
Humidity	0-100% (non-condensing)
