Zebra 105SL Plus User Manual

113
Printer Configuration and Adjustment
Remove Media or Liner from the Rewind Spindle
7/3/13 P1056468-002
Remove Media or Liner from the Rewind Spindle
Rewind mode uses the rewind spindle to wind media, while Peel-Off mode uses the rewind
spindle to wind used liner. Remove the media or the liner from the rewind spindle each time
that you change media.
To remove media or liner from the rewind spindle, complete these steps:
1. Has the media run out?
Important • It is not necessary to turn off the power to remove media or liner from the
rewind spindle. If power is turned off, all label formats and images, as well as any
temporarily saved parameter settings stored in the printer’s internal memory, are lost. When
power is turned back on, these items must be reloaded.
If... Then...
No a. Create slack in the media or liner by rotating the rewind spindle
slightly clockwise.
b. Cut or tear the media or liner at the rewind spindle.
Ye s Continue with the next step.

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
