Zebra 105SL Plus - Load the Media

59
Printer Setup and Operation
Load the Media
7/3/13 P1056468-002
Load the Media
1.
2.
Loosen the thumb screw (not visible from this angle) that is located on the bottom of the
outer media guide (
1).
Caution • The printhead may be hot and could cause severe burns. Allow the
printhead to cool.
Open the printhead assembly by rotating the printhead-open lever (1).
1
1
