Zebra 105SL Plus User Manual

83
Printer Configuration and Adjustment
Changing Printer Settings
7/3/13 P1056468-002
Print Settings
Table 7 • Print Settings
Print
Darkness
Set the darkness to the lowest setting that provides good print quality. If you set the darkness
too high, the label image may print unclearly, bar codes may not scan correctly, the ribbon
may burn through, or the printhead may wear prematurely.
If desired, use the FEED Self Test on page 151 to determine the best darkness setting.
Accepted values:
0.0 – 30.0
Related ZPL command(s):
^MD, ~SD
SGD command used:
print.tone
Control panel menu item: DARKNESS on page 21
Printer web page:
View and Modify Printer Settings > General Setup >
Darkness
Print Speed Select the speed for printing a label (given in inches per second). Slower print speeds
typically yield better print quality.
Accepted values:
• 203 dpi: 2–12 ips
• 300 dpi: 2–9 ips
Related ZPL command(s):
^PR
SGD command used:
media.speed
Control panel menu item: PRINT SPEED on page 21
Printer web page:
View and Modify Printer Settings > General Setup >
Print Speed

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
