Zebra 105SL Plus User Manual

Printer Setup and Operation
Select a Data Communication Interface
42
P1056468-002 7/3/13
Data Cables
You must supply all data cables for your application.
Ethernet cables do not require shielding, but all other data cables must be fully shielded and
fitted with metal or metallized connector shells. Unshielded data cables may increase radiated
emissions above the regulated limits.
To minimize electrical noise pickup in the cable:
• Keep data cables as short as possible.
• Do not bundle the data cables tightly with the power cords.
• Do not tie the data cables to power wire conduits.
Wireless print server Option Limitations and Requirements
• Can print to the printer from any computer on your Wireless
Local Area Network (WLAN).
• Can communicate with the printer through the printer’s web
pages.
• The printer must be configured to use your WLAN.
• A parallel connection or a wired print server (if installed) takes
up this port on the printer.
Configuration Refer to the ZebraNet Wired and Wireless Print
Servers User Guide for configuration instructions. A copy of this
manual is available at http://www.zebra.com/manuals or on the
user CD that came with your printer.
Table 4 • Data Communication Interfaces (Continued)
Interface
Standard or
Option
Description

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
