Zebra 105SL Plus User Manual

Printer Setup and Operation
Select a Data Communication Interface
40
P1056468-002 7/3/13
Select a Data Communication Interface
You may connect your printer to a computer using one or more of the available connections.
The standard connections are shown in Figure 4. A ZebraNet wired or wireless print server
option or a parallel port may also be present on your printer.
Figure 4 • Communication Interfaces
Table 4 on page 41 provides basic information about data communication interfaces that you
can use to connect your printer to a computer. You may send label formats to the printer
through any data communication interface that is available. Select an interface that is
supported by both your printer and your computer or your Local Area Network (LAN).
Serial port
Internal wired Ethernet print server
USB port
Parallel port
Caution • Ensure that the printer power is off (O) before connecting data communications
cables. Connecting a data communications cable while the power is on (
I) may damage the
printer.

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
