Zebra 105SL Plus User Manual

163
Specifications
Print Specifications
7/3/13 P1056468-002
Print Specifications
Refer to the tables that follow for printer specifications.
Print Specifications 203 dpi 300 dpi
Printhead resolution 203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Dot size
(width×length)
0.0049×0.0049 in.
(0.125×0.125 mm)
0.0033×0.0039 in.
(0.084×0.099 mm)
First dot location (measured from
inside media edge)
0.10 ± 0.035 in.
(2.5 ± 0.9 mm)
0.023 ± 0.035 in.
(0.6 ± 0.9 mm)
Maximum print width 4.09 in. (104 mm) 4.09 in. (104 mm)
Maximum print length
(non-continuous)
39 in. (991 mm) 39 in. (991 mm)
Maximum print length (continuous) 150 in. (3810 mm) 100 in. (3810 mm)
Selectable print speeds (inches
per second)
2.4, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 2.4, 3, 4, 5, 6, 7, 8, 9
Bar code modulus (X) dimension:
Ladder (rotated) orientation
Picket fence (nonrotated)
orientation
4.9 mil to 49 mil
4.9 mil to 49 mil
3.9 mil to 39 mil
3.33 mil to 33 mil
Thin film printhead with Element
Energy Equalizer (E
3
)
®
Yes Yes

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
