Zebra 105SL Plus User Manual

Specifications
Features
160
P1056468-002 7/3/13
Features
This section lists the standard and optional features for the printer.
Standard Features
• Thermal transfer and direct thermal printing
• 16 MB SDRAM (12 MB user-available)
• ZebraNet 10/100 Print Server (internal)
•USB 2.0 Port
• RS-232 serial port
• Bidirectional parallel port
• 10/100 internal Ethernet
•Real-Time Clock
• Advanced Counter
• XML-enabled printing
Optional Features
• ZebraNet Wireless Print Server
• Full-width rotary knife cutter and catch tray
• Media rewind spindle
• Factory-installed 64 MB (61 MB user available) Flash memory option
• Additional fonts
Note • Printer specifications are subject to change without notice.

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
