Zebra 105SL Plus User Manual

Specifications
General Specifications
162
P1056468-002 7/3/13
General Specifications
Physical Specifications
Electrical Specifications
Environmental Conditions for Operation and Storage
Dimensions
Height 15.5 in (393.7 mm)
Width 10.31 in. (262 mm)
Depth 20.38 in. (517.5 mm)
Weight without options 50 lb. (22.7 kg)
Power
General 100 to 240 VAC;
47 to 63 Hz
Power consumption printing
PAUSE
test at slowest speed
121 W
Printer idle 20 W
Environment Mode Temperature Relative Humidity
Operation Thermal Transfer 40° to 104°F
(5° to 40° C)
20 to 85% non-condensing
Direct Thermal 32° to 104°F
(0° to 40° C)
Storage Thermal Transfer or
Direct Thermal
–40° to 140°F
(–40° to 60° C)
5 to 85% non-condensing

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
