Zebra 105SL Plus User Manual

165
Specifications
Ribbon Specifications
7/3/13 P1056468-002
Black Mark Sensing
Ribbon Specifications
Refer to the following tables for ribbon specifications.
Media Specifications 203 dpi 300 dpi
Mark length (measuring parallel
to label/tag edge)
Minimum 0.12 in. (3 mm) 0.12 in. (3 mm)
Maximum 0.43 in. (11 mm) 0.43 in. (11 mm)
Mark width (measuring to
perpendicular
label/tag edge)
Minimum 0.43 in. (11 mm) 0.43 in. (11 mm)
Maximum Full media width Full media width
Mark location within 0.040 in. (1 mm) of
the inside media edge
within 0.040 in. (1 mm) of
the inside media edge
Mark density in Optical Density Unit (ODU) >1.0 >1.0
Note • Consider the following when using ribbon:
• Match the ribbon to the label width and printhead width that you are using. The ribbon
should be at least as wide as the labels to protect the printhead from excessive wear.
• Ribbon must be wound with the coated side out.
Ribbon Specifications 203 dpi 300 dpi
Printhead resolution 203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Ribbon width Minimum 0.79 in. (20 mm) 0.79 in. (20 mm)
Ribbon width Maximum 4.33 in. (110 mm) 4.33 in. (110 mm)
Maximum ribbon length 1476 ft (450 m) 1476 ft (450 m)
Ribbon core inside diameter 1.0 in. (25.4 mm) 1.0 in. (25.4 mm)
Maximum ribbon roll outside
diameter
3.2 in. (81.3 mm) 3.2 in. (81.3 mm)

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
