Printer Setup and Operation
Types of Media
48
P1056468-002 7/3/13
Non-Continuous
Fanfold Media
Fanfold media is folded in a zigzag pattern. Fanfold media can
have the same label separations as non-continuous roll media.
The separations would fall on or near the folds.
Continuous
Roll Media
Roll media is wound on a 3-in. (76-mm) core.
Continuous roll media does not have gaps, holes, notches, or
black marks to indicate label separations. This allows the
image to be printed anywhere on the label. Sometimes a cutter
is used to cut apart individual labels.
Table 5 • Roll and Fanfold Media (Continued)
Media Type How It Looks Description

Table of Contents

Other manuals for Zebra 105SL Plus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra 105SL Plus and is the answer not in the manual?

Zebra 105SL Plus Specifications

General IconGeneral
Weight50 lbs / 22.7 kg
Humidity20-85% non-condensing
Print MethodThermal Transfer
Resolution203 dpi (8 dots/mm)
Max Print Width4.09 inches / 104 mm
Max Print Speed12 inches per second / 305 mm per second
Memory16 MB SDRAM, 8 MB Flash
Media Width0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media TypesContinuous, die-cut, black mark
Ribbon Width2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length1476'/450 m
ConnectivityParallel, Serial
Optional ConnectivityEthernet, Wireless
Power Requirements90-264 VAC; 48-62 Hz
Operating Temperature40°F to 105°F / 5°C to 40°C
Storage Temperature-40°F to 140°F / -40°C to 60°C
