Zebra 105SL Plus User Manual

Printer Setup and Operation
Select a Print Mode
52
P1056468-002 7/3/13
Peel-Off Use when the printer has the Rewind option
if you want to remove the labels from the
liner one label at a time.
The printer peels the label from the liner
during printing and then pauses until the
label is removed. The liner winds onto the
rewind spindle.
Red solid lines = media, Blue dotted lines = backing only
Rewind Use when the printer has the Rewind option
if you want to save the labels without
separating them or removing them from
their backing.
The printer prints without pausing between
labels. The media is wound onto the rewind
spindle after printing.
Table 6 • Print Modes and Printer Options
Print Mode When to Use/Printer Options Required Printer Actions

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
