Zebra 105SL Plus - Page 56

Printer Setup and Operation
Load the Ribbon
56
P1056468-002 7/3/13
7.
8.
Thread the ribbon over the media dancer assembly (1) and under the ribbon guide roller
(
2).
Caution • The printhead may be hot and could cause severe burns. Allow the
printhead to cool.
Rotate the printhead-open lever (1) to the open position.
1
2
1
