Zebra 105SL Plus - Page 78

Printer Setup and Operation
Load the Media
78
P1056468-002 7/3/13
10. Tighten the thumb screw (not visible from this angle) that is located on the bottom of the
outer media guide (
1).
11. Push down the printhead assembly (1), and then rotate the printhead-open lever (2) until it
locks into place.
The media winds on the rewind spindle or core.
1
12
