General| Type | Handheld bar code reader |
|---|---|
| Wavelength | 617 nm |
| Sensor type | Linear |
| Scanner type | 1D |
| Read rate (max) | 547 reads/s |
| Pitch reading angle | -65 - 65 ° |
| Motion tolerance (cm/s) | 63.5 |
| Linear (1D) barcodes supported | Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C. |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Input voltage | 5 V |
| Power consumption | 165 mA |
| Power source type | DC |
| Standard interfaces | RS-232 |
| Connectivity technology | Wired |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Certification | EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1 |
| Product color | Black |
| Housing material | - |
| International Protection (IP) code | IP42 |
| Sustainability certificates | RoHS |
Weight and Dimensions| Depth | 99 mm |
|---|---|
| Width | 67 mm |
| Height | 160 mm |
| Weight | 140 g |
