RS-232 INTERFACE 4 - 3
RS-232 Parameter Defaults
Table 4-1 lists the defaults for RS-232 host parameters. If any option needs to be changed, scan the
appropriate bar code(s) provided in the Parameter Descriptions section beginning on page 4-4.
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 4-1 RS-232 Host Default Table
Parameter Default
Page
Number
RS-232 Host Parameters
RS-232 Host Types Standard 4-6
Baud Rate 9600 4-8
Stop Bit Select 1 Stop Bit 4-9
Check Receive Errors Enable 4-9
Parity Type None 4-10
Data Bits (ASCII Format) 8-bit 4-10
Hardware Handshaking None 4-12
Software Handshaking None 4-14
Host Serial Response Time-out 2 sec 4-15
RTS Line State Low RTS 4-16
Beep on <BEL> Disable 4-16
Intercharacter Delay 0 msec 4-17
Nixdorf Beep/LED Options Normal Operation 4-18
Ignore Unknown Characters Send Bar Code 4-18

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
