6 - 6 LI2208 PRODUCT REFERENCE GUIDE
Intra-Keystroke Delay
When enabled, an additional delay is inserted between each emulated key depression and release. This sets
the Keystroke Delay parameter to a minimum of 5 msec as well.
Alternate Numeric Keypad Emulation
In a Microsoft® operating system environment, this allows emulation of most other country keyboard types not
listed in Appendix B, COUNTRY CODES.
Enable Intra-Keystroke Delay
*Disable Intra-Keystroke Delay
NOTE If your keyboard type is not listed in the country code list (see Appendix B, COUNTRY CODES), disable
Quick Keypad Emulation on page 6-7 and ensure Alternate Numeric Keypad Emulation on page 6-6 is
enabled.
*Enable Alternate Numeric Keypad
Disable Alternate Numeric Keypad

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
