Zebra LI2208 User Manual

APPENDIX A STANDARD DEFAULT PA-
RAMETERS
Default Parameters
Table A-1 Standard Default Parameters Table
Parameter Default
Page
Number
USB Host Parameters
USB Device Type USB Keyboard (HID) 3-5
Symbol Native API (SNAPI) Status Handshaking Enable 3-6
USB Keystroke Delay No Delay 3-7
USB CAPS Lock Override Disable 3-7
USB Ignore Unknown Characters Send 3-8
USB Convert Unknown to Code 39 Disable 3-8
Emulate Keypad Enable 3-9
Emulate Keypad with Leading Zero Disable 3-9
Quick Keypad Emulation Enable 3-10
USB FN1 Substitution Disable 3-10
Function Key Mapping Disable 3-11
Simulated Caps Lock Disable 3-11
Convert Case No Case Conversion 3-12
USB Static CDC Enable 3-12
Ignore Beep Disable 3-13
1
User selection is required to configure this interface and this is the most common selection.

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
