Zebra LI2208 User Manual

11 - 8 LI2208 PRODUCT REFERENCE GUIDE
Storage Temperature -40° to 158° F (-40° to 70° C)
Humidity 5% to 95% RH, non-condensing
Drop Specifications Over 100 drops at 5 ft./1.5 m at room temperature; survives 6 ft./1.8 m drops
to concrete
Environmental Sealing IP42
Utilities and Management
123Scan
2
, Scanner Management Services (SMS), Zebra Scanner SDK
See
Appendix E, NON-PARAMETER ATTRIBUTES for definitions and
attribute numbers of non-parameter attributes. This appendix includes
attributes electronically loaded to the scanner either by 123Scan or via SMS.
Accessories Hands-free (gooseneck) Intellistand; auto-host detect cables
Table 11-2 Technical Specifications - LI2208 Linear Imager
Item Description

Zebra LI2208 Specifications

General

Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Linear
Scanner type	1D
Read rate (max)	547 reads/s
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	63.5
Linear (1D) barcodes supported	Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar Expanded, Interleaved 2 of 5, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Input voltage	5 V
Power consumption	165 mA
Power source type	DC
Standard interfaces	RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	EMC FCC Part 15 Class B, ICES 003 Class B, IEC 60601-1-2 Environmental RoHS Directive 2002/95/EEC Electrical Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950-1 LED Class 1
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS

Weight and Dimensions

Depth	99 mm
Width	67 mm
Height	160 mm
Weight	140 g
