Getting Started 1 - 7
Calibrating the Screen
To calibrate the screen so the cursor on the touch screen aligns with the tip of the stylus:
1. Remove the stylus from its holder on the side of the MC55.
2. Carefully press and briefly hold the tip of stylus on the center of each target that appears on the screen.
3. Repeat as the target moves around the screen, then tap the screen to continue.
Resetting the MC55
There are three reset functions, warm boot, cold boot and clean boot. A warm boot restarts the MC55 by closing all
running programs. A cold boot also restarts the MC55, and also initializes some drivers. Data saved in flash
memory or a memory card is not lost.
If the MC55 is not functioning properly, perform a warm boot first. If the MC55 still does not respond, perform a cold
boot.
Performing a Warm Boot
Hold down the red Power button for approximately five seconds. As soon as the MC55 starts to boot release the
Power button.
Figure 1-6
Splash Screen (Warm Boot)
Performing a Cold Boot
To perform a cold boot:
•
On a numeric keypad, simultaneously press the red Power button and the and keys.
•
On an alphanumeric keypad, simultaneously press the red Power button and the and keys.
•
On an PIM keypad, simultaneously press the red Power button and the and keys.
NOTE The Calibration screen can be accessed by pressing Blue key - Backspace key.
