Accessories 2 - 29
Figure 2-29
Insert MC55 into Vehicle Holder
5. Connect the auto charger cable to the MC55 and slide the two locking tabs up to secure the cable cup to the
MC55.
6. Connect the other end to the cigarette lighter socket.
The LED indicator on the right side of the touch screen lights up orange during charging.
Flat Surface Installation
1. Remove the plastic sheet on the bottom of the mounting disc.
2. Place the disc, sticky side down, on a clean flat surface.
Figure 2-30
Mounting Disc
3. Fix the suction cup mount to the disc with the suction lever facing up.
4. Flip the lever down to create a vacuum between the suction cup and the disc.
NOTE Prior to removing the MC55 from the vehicle holder, disconnect the auto-charge cable from the MC55.
