2 - 20 MC55 Integrator Guide
Charging the MC55 Battery
Insert the MC55 into the vehicle cradle to begin charging. A click indicates that the MC55 button release locking
mechanism is enabled and the MC55 is locked in place.
Figure 2-20
MC55 Battery Charging
Removing the MC55
To remove the MC55, press the release levers on the cradle and pull the MC55 up and out of the cradle.
Figure 2-21
Removing the MC55
CAUTION Ensure the MC55 is fully inserted in the cradle. Lack of proper insertion may result in property damage or
personal injury. Zebra is not responsible for any loss resulting from the use of the products while driving.
