Accessories 2 - 25
Figure 2-26
Cable Cup Locking Tabs
4. To remove, slide the two locking tab down and remove the cable from the MC55.
Battery Charging Indicators
The MC55 amber Charge LED indicates the MC55 battery charging status. The 2400 mAh battery charges in less
than four hours and the 3600 mAh battery charges in less than six hours. See Table 1-1 on page 1-6 for charging
status indications.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC55.
