Carl Zeiss Appendix Primo Star / Primo Star iLED
40 M60-2-0011 v 08/2008
En
g
lish
LED illumination
Constant, brightness-independent
color temperature of
Homogeneous field illumination
Suitable for objectives with
magnifications of
Analogous brightness adjustment from
white light LED, peak wavelength 440 nm, LED class 2
7480 K
20 mm diameter
4x to 100x
approx. 15 to 100 %
LED modules
(reflected-light fluorescence illuminator)
max. 40 mW, 365 - 625 nm; LED class 3B
Battery supply unit (accessory)
Batteries
Type
Capacity
Number per battery supply unit
Operational lifetime
fuses according to IEC 127 T4.0 A/H
mono-cell (D) - commercially available, NiCd or NiMH, 1.2 V
minimum 5000 to max. 9000 mAh
5 batteries
several hours, depending on the capacity of the batteries
Optical/mechanical data
Stand with stage focusing
With coarse focusing drive
With fine focusing drive
Total stage lift
45 mm/rev.
0.5 mm/rev.
15 mm
Objective change manual via quadruple objective nosepiece
Objectives infinity-corrected objective range with W 0.8 mounting thread
Eyepieces
With field-of-view number 18
With field-of-view number 20
30 mm tube size
PL 10x/18 Br. foc.
PL 10x/20 Br. foc.
Specimen stage
Dimensions (width x depth)
Stage travel (X x Y)
Coaxial drive
Vernier scales
Specimen holder
mechanical stage 75x30 right/left
140 x 135 mm
75 x 30 mm
optionally right or left
readable from the right
with spring lever, left
Abbe condenser 0.9/1.25; Fixed-Köhler for V
obj
. 4x to 100x
Abbe condenser 0.9/1.25; Full-Köhler for V
obj
. 4x to 100x
Binocular tube 30°/20
Maximum field-of-view number
Interpupillary distance
Tube angle
Viewing height
Viewing port
20
adjustable from 48 to 75 mm
30°
380 to 415 mm
tube factor 1x
Binocular phototube 30°/20
Maximum field-of-view number
Interpupillary distance
Tube angle
Viewing height
Viewing port
Photo/video port
Invariable splitting ratio
20
adjustable from 48 to 75 mm
30°
380 to 415 mm
tube factor 1x
tube factor 1x, 60 mm mount
50% vis / 50 % doc
Illuminating mirror with plane surface and spherical surface with f' = 75 mm
