100
SPECIFICATIONS
General
Operation Voltage 12V (DC)
Operation Voltage Range 10.5~15.8V (DC)
Maximum Operation Current 15A
Grounding System Car Battery Negative Pole
Installation Dimension (WxHxD) 178 x 100 x (162+18)mm
Installation Angle 0°~30°
Net Weight 2.9 kg
FM
Signal Noise Ratio ≥55dB
Residual Noise Sensitivity (S/N 30dB) 20dBu
Frequency Response (±3dB) 40Hz~14KHz
Station Seeking Level 20~28dBuV
Distortion ≥1.0%
Stereo Seperation (1 Khz) ≥25dB
Antenna Impedence 75
AM
Residual Noise Sensitivity (S/N=20dB) 14dBu
Amplitude (±9KHz) ≥50dB
DVD Player
Signal/Noise Ratio 80 dB
Dynamic Range 90 dB
Distortion (line out) ≥0.1%
Frequency Range (±3dB) 20Hz~20KHz
Maximum Output Power 4x50W
Load Impedance 4
USB
Compatible with FAT Format
Constant current 500mA
AUX IN
Distortion ≥0.3%
Frequency Response (±3dB) 20Hz~20KHz
Audio Input Level ≥1.1Vrms
Audio
Audio Output Impedence 600
Audio Output Level 4Vrms
(Under normal audio input level at maximum output volume)
Video
Normal Video Input Level:
CVBS 1.0±0.2V
RGB 700mV
Video Input Impedence 75
Video Output Impedence 75
Video Output Level 1.0±0.2V
(Under normal video input level)
TFT Monitor
Screen Diagonal 6.5 inches
Usable Display Area 143.4 (W) x 79.32 (H) mm
Resolution 400(RGB) (W) x 234 (H)
Brightness 350cd/m
(Center brightness measured after 30 minutes)
