Page 33
TO GET ASSISTANCE, CALL: 919-774-7667
ZENITH PUMPS
Master/Follower System (cont’d)
5. Result:
• Turn on the AC power for both systems
• Input Follower Primary Setpoint 1 (Code 01), i.e., 75 (%)
• Input Master Primary Setpoint 1 (Code 01), i.e., 20 (cc/min)
• The master system should run, and the follower system should run and deliver 75% the
flowrate the master system delivers
• Stop the master system, the follower will also stop
6. IMPORTANT NOTE:
• The above master/follower system is only a simplest example. For more detailed sys-
tem integration and configuration, please refer to Chapter 5 in “ZeDrive and ZeTrol
Manual”
