Page 52
TO GET ASSISTANCE, CALL: 919-774-7667
ZENITH PUMPS
M51
Entry Error
Read Only
Units:
Range:
0
No Error
1
Invalid Code
2
Above Maximum Value
3
Below Minimum Value
4
Keypad Lockout
5
Entry Timeout
M52
Alarm Status
Read Only
Units:
Range:
1
Low Limit
2
High Limit
3
Low Alarm
4
High Alarm
5
Error Alarm 1
6
Error Alarm 2
7
Current Limit
M53
Control State
Read Only
Units:
Range:
1
JOG
32
RUN
64
Ramped Stop
128
Fast Stop
M54
Control Mode
Read Only
Units:
Range:
Bit 7
Primary (1) / Secondary (0) Data Set
Bit 6
Not used (was the forward /reverse flag on ZeTrol)
Bit 5
Closed-Loop (1) / Open-Loop (0)
Bit 4
Primary Setpoint 1 (1) / Primary Setpoint 2 (0)
Bit 3
Secondary Setpoint 3 (1) / Secondary Setpoint 4 (0)
Bit 2
Local (1) / Remote Serial (0) Control
Bit 1
Keypad Enable (1) / Disable (0)
Bit 0
Ramp Enable (1) / Disable (0)
It shows the status of control state of the controller.
It indicates the status of the optional switch inputs to the
controller. It is a single-byte with meanings assigned to
individual bits. This code, along with Code 53, is
intended for use by computer interface.
It shows the last error encountered on a keypad entry. If
any entry is not accepted by the controller, the reason
shows up here.
It shows the status of limits and alarms in the controller.
