Page 53
TO GET ASSISTANCE, CALL: 919-774-7667
ZENITH PUMPS
M55
Analog Input 1 Raw Signal
Read Only
Units:
mA / VDC
Range:
M56
Analog Input 1 Adjusted Signal
Read Only
Units:
bits
Range:
M57
Power Fail Count
Read Only
Units:
count
Range:
M58
Serial Communications Error
Read Only
Units:
Range:
0
No Error
Bit 5
Data was out of minimum/maximum range
Bit 4
Invalid Parameter Code, Check Sum or Decial Point Error
Bit 3
Receive Buffer filled before ETX received or Message Format Error
Bit 2
Parity Error
Bit 1
Controller in Local Mode, Not in Computer Mode
60
Current Limit Response
Default:
20
Units:
Range:
0~50
61
Primary Scaling Format
Default:
1
62
Secondary Scaling Format
Default:
1
Units:
Range:
0
Direct
1
Master
2
Follower
3
Offset
It is Analog Input 1 signal unadjusted for Zero and Span.
It is Analog Input 1 signal adjusted for Zero and Span.
It represents the number of times that a power brownout
condition was detected.
It is one of few monitoring codes which can be altered
from keypad. When displayed, this number can be
zeroed by pressing CLEAR key on keypad.
It shows the status of the most recent data received from
serial communications port.
It defines how aggressively the software algorithm
address the condition of current limit (i.e. how quickly
the phase-angle firing is adjusted to reduce current).
These parameters select Output Format when primary
and secondary data sets are selected, respectively.
