26
Controlling Fixtures
Once you have added your xtures to the desk, you are ready to start controlling them.
Selecting Fixtures
Press the FIXTURES key. The MFKs become xture selection buttons and the LCDs above the keys indicate what xture
has been assigned to which MFK. Press the MFK to select the xture; press it again to deselect the xture. Note that
you can multi-select xtures by holding the rst xture button down whilst tapping the last xture button (all intermediate
xtures will be selected).
Homing Fixtures
The easiest way to see which xtures in the rig you are controlling is to ‘home’ them. This sets their parameter values to
the Home values dened in the Edit Fixtures table in Setup. Typically these are position (Pan and Tilt) to 50%, the dimmer
to 100% with an open white beam (shutter open, no gobos or effects).
With your xtures selected, press the HOME key. This sends all the parameters of the selected xture(s) to their home
values and automatically tags the xture parameters.
Controlling Fixture Parameters
Each xture type has it’s own set of parameters (intensity, color, gobo, pan, tilt etc.) which are classied or grouped
together into different attributes (Colour, Beamshape and Position). Once a xture has been selected, the attribute buttons
and control wheels can be used to adjust the parameter output levels as required.
Controlling Intensity
The Intensity parameter of a xture is adjusted by control wheel. First select the xture(s) required as described above
and then press the POSITION key (if not already selected). The intensity parameter is assigned to the second nger wheel.
Use the control wheel to adjust the intensity level as required. The output value is shown on the Wheel LCD above the
corresponding control wheel.
Tip – No Intensity Output ?
If the intensity output levels do not change when you adjust the intensity parameter using the wheel, check that the
GRAND MASTER fader is at full and the BLACKOUT button is off. If the selected fixture(s) have a Shutter parameter,
check that the shutter is open.
Controlling Colour, Beamshape and Position Parameters
The colour, beamshape and position parameters of the selected xture(s) are controlled using the control wheels.
First select the required xture(s) and then press one of the attribute keys (COLOUR, BEAMSHAPE or POSITION).
The corresponding parameters for the xture(s) are assigned to the control wheels and are indicated on the Wheel LCD.
If the xture has more than three controllable parameters for the selected attribute, press the attribute key again to select
the next group of parameters.
Controlling Fixtures
