Setting the DMX Start Address
Once you have selected the required xture type (eg MARTIN MAC 500 Mode 4), you can set the DMX start address
for the xture(s):
Select the DMX universe (1-4) and enter the required start address using the MFKs or directly into the eld on the popup
window on the monitor.
To patch to the next available address in the selected universe use the [Next Address] MFK or soft button on the window.
Press ENTER to conrm.
Assigning Fixture Type to MFKs
Having selected the required xture type and specied a DMX start address, you now tell the desk where you would like
these xtures to be. Press the MFK for the xture you require – the LCD above it will change to show the xture assigned
to the MFK and the DMX address for this xture. There are 10 pages of 20 xtures available.
When you have assigned the xture type to the required xture selection key(s), press ENTER to return to the Patch
options.
Note – Fixture Types
The complete Zero 88 Fixture Library is stored on the desk, but it is also possible to load additional fixture types from
a memory stick. If the fixture type you require is not in the fixture library on the desk you can import the fixture type –
see Setup chapter of the full User Manual for further details.
Auto Menus
The desk can generate automatic groups, palettes and macros based on the different xture types that have been
assigned.
To generate any or all of these items, press the [Auto Menus] MFK, then press [Create Auto Groups], [Create Auto
Palettes] or [Create Auto Macros] MFK.
For further details see the Setup chapter of the full user manual.
