Playback Controls
Playback X (Memory) Master Fader
The MASTER fader controls the maximum output level of the memory being output on the Playback X. This fader only
affects the dimmer and brightness xture channels (if applicable). The Colour, Beamshape and Position xture channels
are not affected by the master fader.
Go Button
The GO button is used to initiate a crossfade between the memory currently being output and the Next memory in the
memory stack as indicated on the Memories screen.
Pause Button
The PAUSE button is used to pause a crossfade between the current and next memories. When a crossfade has been
paused, the red light in the button ashes. Pressing the GO button releases the pause. Pressing Pause again will step
backwards in the cue stack.
Override Control
The OVERRIDE control is used to slow down or speed up the crossfade between the current and next memory. When
the control is moved away from the central neutral position, this is indicated on the monitor screen.
Step Button
The STEP button is used to manually step through any chase memory with manual drive currently being output on the
Playback X.
Figure 7 - Playback X Controls
