22
C3 Pro Series Access Control Panels and ZKBioSecurity 3.0 Quick Start Guide
Installation Diagram
Sensor
CEILING
INDOOROUTDOOR
C3 Pro Access Control Bundle
Electric Lock
Exit Button
Indoor Wiegand card readerOutdoor Wiegand card reader
Figure 33
Ethernet Communication wire
220/110 V Input
