ZKTeco C3 Pro User Manual

6
C3 Pro Series Access Control Panels and ZKBioSecurity 3.0 Quick Start Guide
Product PIN Diagram
Figure 1
4 Aux Inputs Reserved
Lock Power
Power
4 Lock & Door Sensor
4 Aux Output
RS485 Communication
DIP Switches
Ethernet Port
#1 Door Exit Button #1 Door Card Reader #2 Door Exit Button #2 Door Card Reader #3 Door Exit Button #3 Door Card Reader #4 Door Exit Button #4 Door Card Reader
485 LED
Status LED
ACT LED
SD Card Slot

ZKTeco C3 Pro Specifications

General

Brand	ZKTeco
Model	C3 Pro
Category	IP Access Controllers
Language	English
