18
ULTIMA INSTALLATION GUIDE | 2019 - v1
Connecting the relay module
Connect the cables between the relay module and the main board
Relay module
port connector
12V 2A power
connector
Motherboard
RFID
BAR
WG_IN
FP
USB Reserve
USB Reserve
POWER PORT
Relay module port connector
12V 2A power out
