ULTIMA INSTALLATION GUIDE | 2019 - v1
If you plan to install certain optional modules to the Ultima, follow the step-by-step instructions in this guide. Note the following:
• The optional modules have components and cables that must be attached to the Ultima in a certain order during specic stages of the installation.
• You can only choose one between the barcode and magnetic modules.
– The modules combination can be as follows
– Base+ Fingerprint & RFID module;
– Base+ RFID module;
– Base+ Barcode/Magnetic module;
– Base+ Fingerprint & RFID module+ Barcode/Magnetic module;
– Base+ RFID module+ Barcode/Magnetic module.
– Internal Relay Module
– Internal PoE Module
Keypad Fingerprint &
RFID module
RFID module Barcode module Magnetic module Relay module PoE module Battery
Optional Modules
