ULTIMA INSTALLATION GUIDE | 2019 - v1
Required personnel
Depending on the modules that you purchased, and the implementation
planned for your site, you will require the following:
• A licensed electrician to install or move AC outlets and power cables.
• A qualied person to run Ethernet cable.
One or more qualied installers to assemble the device and mount it on the wall (a
second person may be necessary to hold the cover while the other person attaches
components to the cover and base).
Planning
Power sources and connections
Requirements:
• The AC power source must be grounded 100 to 240V AC, 50/60Hz input voltage.
• A licensed electrician must ensure that low-voltage wiring is routed securely away
from high-voltage wiring.
Power source options:
The following power supply methods are available:
• Mounted near an AC outlet, with power supply plugged in
• Power-over-Ethernet (PoE)
• Backup battery
Ethernet connection
• Location - Plan to install the Ultima in a location that allows an easy and secure
connection to an external network (for example, using the Ethernet cable).
• All cables must be in place before installing the Ultima.
Mounting template
The packaging box includes a paper mounting template that you use to
mark the wall with the following measurements and indicators:
• Where to screw the base of the unit into the wall
• Where cables enter the unit through access holes in the wall
