ULTIMA INSTALLATION GUIDE | 2019 - v1
Fingerprint Connector
Barcode & Magnetic card reader Connector
RFID Connector
Motherboard
RFID
BAR
WG_IN
FP
USB Reserve
USB Reserve
POWER PORT
Wire Clamps
Connecting the module wires to the motherboard
1. Route the module cable(s) as shown
2. Secure the wires with the wire clamps
