ZKTeco Ultima Series Installation Guide

29
ULTIMA INSTALLATION GUIDE | 2019 - v1
RFID
BAR
WG_IN
FP
USB Reserve
USB Reserve
POWER PORT
Power IN Connector
Power plug Adaptor
Connecting AC power supply
1. Route the Ethernet cable RJ45 through
the back top or bottom hole*
2. *if the keypad is not going to be installed.
3. Connect the power plug adaptor external
power supply plug and other end to the
mother board.
