ULTIMA INSTALLATION GUIDE | 2019 - v1
Location
• Ultima is designed for any internal environ-
ment. In rare cases, user sites may contain
agents in nature that can corrode the electron-
ics assemblies in these devices. In the event of
this situation, users must move the devices to a
suitable environment.
• Install the Ultima in an area where the screen is
not exposed to direct sunlight or other high-in-
tensity lighting that could make the screen
dicult to read.
Minimum 10ft (3m)
6.5ft (2m)
Lux References Guide
10 LUX 1200+ LUX 0-800 LUX (Recommended)
Avoid these situations
Direct sunlight outdoors Direct sunlight through windows Too close to light xturesSunlight reection o an object
Installation Environment
Recommended Locations
The device should only be installed indoors. The illuminance of the external light source is 0-8000LUX. Direct sunlight
should be avoided. Install the device at least 10 feet (3m) away from windows, and 6.5 feet (2m) away from light xtures.
Avoid direct sunlight, indirect sunlight reected o mirrors, or bright articial light.
