ZKTeco Ultima Series Installation Guide

22
ULTIMA INSTALLATION GUIDE | 2019 - v1
Pan head screws
(supplied)
4. Insert back the end-cap rst *
* Fingerprint and RFID module only
5. Place the face-plate panel back on to the
housing and push it gently until it snaps.
3. Secure module housing to the base
component with 2 screws.
CONFIGURATIONS
D GF B

ZKTeco Ultima Series Specifications

General

Brand	ZKTeco
Model	Ultima Series
Category	IP Access Controllers
Language	English
