ZMC420SCAN Motion Controller Hardware Manual V1.5
ON, PWM will output actually, in this way, laser energy can be controlled.
➢ ZMC420SCAN OUT0-7 have the function of precision output, and each precision output function
is independent, and the same one MOVEOP_DELAY and AXIS_ZSET can be used to set whether
each MOVE_OP uses precision output and precision output delay function or not, then achieve
laser PSO control.
➢ Single-ended pulse axis 6-11 need to be configured as local axes compulsively through
AXIS_ADDRESS, then they can be used, and they are general outputs when ATYPE=0.
3.5.1. Digital Output Specification & Wiring
→ Specification
High Speed Output (OUT0-11)
NPN leakage type, it is 0V when outputs
Max leakage
current when off
1μs (resistive load typical value)
Note:
The times in the form are typical based on the resistive load, and may change
when the load circuit changes.
Due to the leak-type output, the shutdown of the output will be obviously
affected by the external load circuit, and the output frequency should not be set
too high in the application.
